School

Petroleum Engineering

.

.

facilities and

Infrastructure

.

Sludge

Laboratory


Experimental tests are developed in the sludge laboratory to monitor the physical and chemical condition of drilling fluids, detect changes in their properties and possible behavioral anomalies caused by pollutants present in perforated formations, assess appropriate treatment, and take the necessary actions to ensure compliance with the required functions. Technical tests include: sludge density, total solids, sand content, rheological behavior, plastic viscosity, apparent viscosity, yield point, gel point, viscosifying performance, filter volume, revoque characteristics, pH, alkalinity, Hardness, Salinity, Methylene Blue Test.

The Sludge Laboratory of the EIP fulfills the function of supporting the material that bears the name of Drilling Sludge, as well as supporting the experimental phase of undergraduate and postgraduate students who are developing degree projects in the drilling area and that require the realization of tests to a drilling sludge formulated and elaborated there for this purpose.

In the EIP Sludge Laboratory, no software is used, since all the equipment is field equipment that only requires the intervention of the operator.

Tests

Equipment

Sludge density or weight, sand content and Marsh viscosity

Field Kit (Sludge Scale, Sand Measurement Kit and Marsh Funnel)

Solids content

10 ml Retort Equipment

Sludge flow properties and viscosifier performance

Rotary viscometer type Fann 35 A

Study and control of filtration

Filter API press and HPHT filterpress

     Análisis químico y Prueba de Azul de Metileno (MBT)

Chemical analysis kit (Alkalinity, Chlorides and Water Hardness) and heating plate (Hotplate)

Chemical Analysis and Methylene Blue (MBT) Test

Electrical stability meter for emulsions model 23E

Support for all tests

Mixer Model HMD400, electronic balance (accuracy of 0.1 g) and exhaust and exhaust cabin of gases and fumes

Mario Torres

Lópezmtorresl@uis.edu.co

Petroleum Geology

Laboratory


In this laboratory they carry out preservation, management and analysis activities of various types of rock samples, including lithological description at the level of chemical and modal composition, geometry, texture, density, granulometry, mineralogy, present structures and other geological and sedimentological properties of particular importance for the characterization of structures present in oil and gas fields.

  • Teaching
  • N/A
  • Petrographic microscopes, fluoroscope with ultraviolet and white light selector, GPSMAP 64s with barometric altimeter and a three-axis compass, Brunton Compasses, Oregon GPS 550t, among others.

Alexander Beltran Barrera

abelbar@uis.edu.co


Petrophysics

Laboratory


This laboratory allows analysis of the properties of the rocks and their interaction with the fluids of the deposit. Basic and special petrophysical properties such as porosities, fluid permeability and saturations, wetbility, interfacial stress, among others, parameters necessary in reserve assessment, determination of the capacity of the porous medium to produce hydrocarbons, experimental studies to assess compatibility of injection fluids and damage to formation can be measured directly in samples of hearts and sedimentary rocks

  • Teaching
  • N/A
  • Stereoscopes, Fluoroscope, Granulometric Analysis Ruska Gas and Liquid Permeometers, Hydrostatic Core Holder, Analytical Balance, Recirculating Thermal Bath, Conventional Drying Oven, Wetting Cells (Amott-Harvey Method), Digital King Foot Calibrator, Glass Desiccators, Vacuum Pumps, Heating Plate with Magnetic Shaker, among others.

Felix Arenas

Ruedafearenas@uis.edu.co

Fluid

Laboratory


This laboratory experimentally and analytically studies the main properties of fluids produced in the hydrocarbons industry and their liquid derivatives, as well as their behavior under specific operating conditions in compliance with ASTM standards, APIs and selected field protocols. The laboratory has specialized equipment, materials and instrumentation necessary to determine physical properties associated with fluid quality and treatment needs, such as density, API gravity, water and sediment content (BSW), salinity, selection of chemical demulsicants, viscosities, among others. Parameters necessary to assess safe conditions during transport, storage and marketing, such as the point of fluidity, spark and fire points and vapour pressure of liquid mixtures, among others, can also be determined.

  • Teaching
  • N/A
  • Centrifuges, conventional electric furnace, gas and fume extraction hood, constant temperature baths, electric heater, electronic balances, hydrometers, bronze piston cylinder, kinematic viscometers, Saybolt viscometers, Flat bottom cylinders and insulating cover with coolant for Fluidity Point. Steam and liquid pressure gauges and exchangers for Vapor Reid pressure. Equipment to determine Spark point and fire type Cleveland open cup, Pensky Martens closed testers and Tag Closed Tester, ASTM atmospheric distiller, among others.

Felix Arenas

Ruedafearenas@uis.edu.co

eip.labfluidos.uis.edu.co


Petrophysical Analysis

Laboratory


The Laboratory of Petrophysical Analysis we carry out tests in practices to Students, on Preservation of nuclei, Lithological Description, Granulometry, Fluoroscopy, Gas Permeability and Porosity.

  • Academic – Classes for Students.
  • Stereoscopes
  • Electromechanical Sieve
  • Fluoroscope
  • Ruska gas permeameter
  • Equipment to determine Porosity with vacuum pump.

Felix Arenas

Ruedafearenas@uis.edu.co


Laboratory

Phase Behavior


It allows mainly water, chemical and steam injection procedures.

  •  Teaching, Research, Extension
  • N/A
  • Radial displacement equipment that allows the escalation of the recovery techniques, as well as equipment that allows the reproduction of the most representative improved recovery techniques, including steam injection and cyclic processes.

Samuel Fernando

Muñozsamuel@uis.edu.co

Sample Extraction and Cleaning

Area


It allows the cleaning of the heart and trench samples, as well as the cutting of consolidated and unconfirmed cylindrical samples in hearts.

  • Research, Extension
  • N/A
  • The area has a set of heaters and cleaning systems (capacity ball, soxhlet, condenser), cutters and profilers for cylindrical samples of hearts.

Eduardo Gómez

Cepedalabpetrofisicos@uis.edu.co


Basement

GUATIGUARA-EDI-S03


In this area the nuclei are cut to extract small samples that are used for basic and special petrophysical analysis.

  •  Research, Extension
  • N/A
  • The area has a group of core cutters, as well as a core gamma equipment.

Eduardo Gomez

Cepedalabpetrofisicos@uis.edu.co

Petrophysical Analysis

Laboratory


It allows the basic characterization of fluids, the evaluation of fluid-fluid interaction in the application of chemical treatments in deposits, the determination of concentrations of compounds and elements using spectroscopy techniques, and the assessment of damage to training.

  •  Research, Extension
  • N/A
  • The laboratory has the reagents and elements for pH, turbidity, density, solubility and refractive index measurements, as well as visual wetbility, detergency, emulsions and sludge tests. It also has a spectrophotometer and a mass spectroscopy equipment type ICP (inductive coupling plasma). Finally, it has a measuring equipment of the minimum inhibitory concentration of additives in the control of inorganic scales, and a coreflooding equipment.

 Eduardo Gomez

Cepedalabpetrofisicos@uis.edu.co

Cupiagua

Classrooms


Classrooms.

  • Teaching
  • N/A
  • Video Beam

Eugenia Raquel Durán

Flórezescpet@uis.edu.co


Casabe

Classrooms


Classrooms.

  • Teaching
  • N/A
  • Video Beam

Eugenia Raquel Durán

Flórezescpet@uis.edu.co

Caño Limón

Classrooms


Classrooms.

  • Teaching
  • N/A
  • Video Beam

Eugenia Raquel Durán

Flórezescpet@uis.edu.co


Castilla

Classrooms


Classrooms.

  • Teaching
  • N/A
  • Video Beam

Eugenia Raquel Durán

Flórezescpet@uis.edu.co

Quifa

Classrooms


Classrooms.

  • Teaching
  • N/A
  • Video Beam

Eugenia Raquel Durán

Flórezescpet@uis.edu.co


Chichimene

Classrooms


Classrooms.

  • Teaching
  • N/A
  • Video Beam

Eugenia Raquel Durán

Flórezescpet@uis.edu.co

Third Generation

Classrooms


Classrooms.

  • Teaching
  • N/A
  • Video Beam

Eugenia Raquel Durán

Flórezescpet@uis.edu.co


Rubiales

Classrooms


Classrooms.

  • Teaching
  • N/A
  • VideoBeam

Eugenia Raquel Durán

Flórezescpet@uis.edu.co

Cusiana

Classrooms


Classrooms.

  • Teaching
  • N/A
  • Video Beam

Eugenia Raquel Durán

Flórezescpet@uis.edu.co
